TANDEM AXLE DUMP DT.14K
Standard Features
| GVWR: | 14,000 lbs |
| DT6 - DT6.5 MODELS: | (2) 7,000 lbs Drop Axles w/ Easy Lube Spindles |
| DT83 MODELS: | (2) 7,000 lbs Axles w/ Easy Lube Spindles |
| SUSPENSION: | Slipper Spring Suspension |
| TIRES: | ST235/80R16 LRE Radial |
| BRAKES: | Electric on Both Axles |
| COUPLER: | Adjustable 2-5/16" Coupler or 3" Lunette Eye |
| JACK: | 12,000 lbs Drop Leg Jack |
| HOIST FEATURES: | 3,000 psi Hydraulic Power Pack 20' Hand Remote and Wireless Remote 10' - 14' Models: 5" Hydraulic Cylinder & Scissor Hoist 16' Models: 6" Hydraulic Cylinder & Scissor Hoist Interstate Extreme Cycle Battery and Plug In Charger Lockable Steel Toolbox |
| DECK HEIGHT: | 25" (6'W & 6.5'W) 29" (83"W) |
| SIDES: | 20" Solid Steel + 10" Wood Plank |
| DOOR: | Barn Doors with Cam Lock Two-way Gate |
| LOAD COVER: | Shielded Tarp & Roller |
| FLOOR: | Steel |
| TONGUE LENGTH: | 52" |
| TIE DOWNS: | (4) Heavy Duty Welded In D-rings |
| SPARE TIRE MOUNT: | Passenger's Side of Box |
| LIGHTS: | Sealed Beam, L.E.D. |
| ELECTRICAL: | Sealed Harness System |
| PLUG: | 7-way RV Plug |
| FINISH: | Powder Coat + Scorpion Stone Guard |
Models
| Number | Size | Weight | Payload | Links |
|---|---|---|---|---|
| DT610-14K | 71.5" X 10' | 3,177 lbs | 10,823 lbs | |
| DT612-14K | 71.5" X 12' | 3,409 lbs | 10,519 lbs | |
| DT6.512-14K | 77.5" X 12' | 3,554 lbs | 10,446 lbs | |
| DT6.514-14K | 77.5" X 14' | 3,848 lbs | 10,152 lbs | |
| DT6.516-14K | 77.5" X 16' | 4,823 lbs | 9,177 lbs | |
| DT8312-14K | 83" X 12' | 3,615 lbs | 10,385 lbs | |
| DT8314-14K | 83" X 14' | 3,913 lbs | 10,087 lbs | |
| DT8316-14K | 83" X 16' | 4,901 lbs | 9,099 lbs |
