SINGLE AXLE GRAVITY TILT TL.7K
Standard Features
| GVWR: | 7,000 lbs |
| AXLES: | (1) 7,000 lbs Axles w/ Easy Lube Spindles |
| SUSPENSION: | Torsion Suspension |
| TIRES: | ST235/80R16 LRE Radial |
| BRAKES: | Electric |
| COUPLER: | Adjustable 2-5/16" Coupler or 3" Lunette Eye |
| JACK: | 7,000 lbs Drop Leg Jack |
| DECK HEIGHT: | 20" |
| FLOOR: | Pressure Treated Wood |
| TONGUE LENGTH: | 50" |
| TIE DOWNS: | Stake Pockets, (4) D-rings |
| SPARE TIRE MOUNT: | Passenger's Side, Removable |
| LIGHTS: | Sealed Beam, L.E.D. |
| ELECTRICAL: | Sealed Harness System |
| PLUG: | 7-way RV Plug |
| FINISH: | Powder Coat + Scorpion Stone Guard |
Models
| Number | Size | Weight | Payload | Links |
|---|---|---|---|---|
| TL612-7K | 72" X 144" | 1,424 lbs | 5,576 lbs | |
| TL614-7K | 72" X 168" | 1,644 lbs | 5,356 lbs | |
| TL712-7K | 80" X 144" | 1,496 lbs | 5,504 lbs | |
| TL714-7K | 80" X 168" | 1,644 lbs | 5,356 lbs |
