BEAVERTAIL PINTLE SERIES BT.24KD
Standard Features
| GVWR: | 24,000 lbs |
| AXLES: | (2) 12,000 lbs Axles, Dually w/Easy Lube Spindles |
| SUSPENSION: | Slipper Spring Suspension |
| TIRES: | ST235/80R16 LRE Radial |
| BRAKES: | Electric on All Axles |
| COUPLER: | Adjustable 2-5/16" Coupler or 3" Lunette Eye |
| JACK: | 12,000 lbs Drop Leg Jack |
| DECK HEIGHT: | 36" |
| FRAME: | Light Weight, Rigid Frame Crossmembers every 16" |
| BEAVERTAIL: | 5' Beavertail with Wood Floor |
| RAMPS: | 5' Spring-Assisted Wedge Ramps |
| FLOOR: | Pressure Treated Wood |
| TONGUE LENGTH: | 62" |
| TIE DOWNS: | Stake Pockets & Rub Rails |
| SIDE STEPS: | On Both Sides |
| SPARE TIRE MOUNT: | Optional - Tongue Mount Only |
| LIGHTS: | Sealed Beam, L.E.D. |
| ELECTRICAL: | Sealed Harness System |
| PLUG: | 7-way RV Plug |
| FINISH: | Powder Coat + Scorpion Stone Guard |
Models
| Number | Size | Weight | Payload | Links |
|---|---|---|---|---|
| BT25-24KD | 102" X 25' | 5,749 lbs | 18,251 lbs | |
| BT28-24KD | 102" X 28' | 6,107 lbs | 17,893 lbs | |
| BT30-24KD | 102" X 30' | 6,313 lbs | 17,687 lbs |
